Díly pro EXHAUST SYSTEM
Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
---|---|---|---|
1 | 81305579000 SILENCER 250FC |
7 672 Kč | |
2 | 8130501100030 HEAT SHIELD BLACK |
180 Kč | |
3 | 81305011050 THERMAL PROTECTION FOIL |
340 Kč | |
4 | 81305579080 SILENCER HOUSING |
3 201 Kč | |
5 | 0081050121 EJOT PT SCREW K50X12 |
21 Kč | |
8 | 77705079050 CONNECTING CAP CPL. |
4 209 Kč | |
9 | 81305069000 BUSHING 7,5X12X20 |
134 Kč | |
10 | 0137060003 SPRING WASHER DIN 137 B - 6 |
17 Kč | |
11 | 77205169000 BUSHING 7.5x12x28x8.3 11 |
82 Kč | |
12 | 77205068000 DAMP. COMPON. BLACK |
69 Kč | |
13 | 0770740015 O-RING 74,00X1,50 FKM 75SH |
58 Kč | |
14 | 0025080306 HH COLLAR SCREW M8X30 TX40 |
32 Kč | |
15 | 0025060356 HH COLLAR SCREW M6X35 TX30 |
29 Kč | |
16 | 0025060206 HH COLLAR SCREW M6X20 TX30 |
29 Kč | |
17 | 77308013010 COLLAR BUSH. F.REAR FENDER 07 |
106 Kč | |
20 | 50305016000 TEN.SPRING L=62MM EY.MOVEABLE |
98 Kč | |
21 | 50305116000 TEN.SPRING L=75MM EY.MOVEABLE |
82 Kč | |
22 | 78105081010 SCREW TORX M5X10 |
15 Kč | |
30 | 77705079060 ENDCAP CPL. |
2 686 Kč | |
34 | 77705078640 ROCKWOOL PREFORMED |
1 703 Kč | |
40 | 77705007000 EXHAUST MANIFOLD SX |
7 645 Kč | |
43 | 59405069000 BUSHING FOR EXHAUST SUPPORT 03 |
140 Kč | |
45 | 54603048000 RANGE CHANGE METAL NUT M8 |
52 Kč |
