Díly pro LIGHTING SYSTEM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 81314001000 HEAD LAMP |
1 984 Kč | |
| 3 | 54611038012 BULB HS1 12V 35/35W WHITE |
397 Kč | |
| 4 | 0081050181 SCREW FOR PLASTIC K50X18 T20 |
20 Kč | |
| 7 | 49011435100 BULB 12V 5W (W2,1X9,5D) PHIL. |
68 Kč | |
| 8 | 78114001050 LAMP BRACKET CPL. 2014 |
841 Kč | |
| 20 | 78114040000 REAR LIGHT |
1 878 Kč | |
| 25 | 75014047000 LICENSE PLATE ILLUMINATION 07 |
212 Kč | |
| 26 | 77711081000 FLASHER WIR. HARNESS 14 |
818 Kč | |
| 28 | 0081250181 SCREW FOR PLASTIC 50X18 T20 |
17 Kč | |
| 29 | 0017060255 EJOT PT SCREW K60X25-Z SW6 |
17 Kč | |
| 30 | 54814025200 FLASHER CPL. FR.L/S RE.R/S 09 |
567 Kč | |
| 31 | 54814026200 FLASHER CPL. FR.R/S RE.L/S 09 |
567 Kč | |
| 32 | 44111015100 BULB 12V 10W (BA15S) |
76 Kč | |
| 33 | 0125100003 WASHER DIN 125 A 10.5 |
13 Kč | |
| 34 | 0797100003 LOCK WASHER DIN6797-J10,5 ZI |
17 Kč | |
| 35 | 58414030000 HH COLLAR NUT M10X1,25 WS=13 |
36 Kč | |
| 36 | 54814028000 FLASHER LENS L/S R/S 05 |
130 Kč |
