Díly pro LUBRICATING SYSTEM

Číslo dílu
na schématu
Kód dílu
Název dílu
Cena za kus
vč. DPH
Doporučený
počet
3 78038001017
OIL PUMP GEAR 17 T
68 Kč
4 0458030080
CYLIND.SCREW M3X8 ISO 14580 SS
37 Kč
5 75030003050
STOP SHEET MEMBRANE 07
28 Kč
7 75030003051
MEMBRANE 07
21 Kč
8 81205027003
MEMBRAN CRANKCASE
76 Kč
9 81205027004
TAB WASHER MEMBRAN CSC
76 Kč
10 78138102000
OIL PUMP SHAFT SP-DP
575 Kč
11 0402041580
NEEDLE ROLLER NRB 4X15.8 G2
36 Kč
12 61238111000
ROTOR-SET CPL. 22MM
1 041 Kč
13 0770440020
O-RING 44,00X2,00 VITON
50 Kč
14 78038004000
OIL PUMP COVER SUCTION PUMP
456 Kč
16 0025060166S
HH COLLAR SCREW M6X16 TX30 SL
29 Kč
17 58038022000
CU-SEAL RING DIN7603-12X18X1,5
28 Kč
18 58030021100
OILDRAIN PLUG WITH MAGNET
196 Kč
20 0799060000
TAB WASHER DIN6799-RS 6,0
17 Kč
21 58038007755
STOP DISK 8,1 X 15 X 0,5
21 Kč
22 78138001029
IDLER GEAR 1 29Z
76 Kč
24 78138003000
OIL PUMP COVER
400 Kč
25 59038011012
OILPUMP ROTOR 12MM G-95R/003
708 Kč
26 0770012021
O-RING 12X2 VITON GREEN
25 Kč
27 0402251980
NEEDLEROL.DIN5402 NRA 2,5X19,8
20 Kč
28 0402251180
NEEDLE ROLLER DIN5402 2,5X11,8
19 Kč
29 0770020170
O-RING 17,17X1,78 GLO
18 Kč
30 78138015001
OIL SCREEN CPL.
483 Kč
31 59038017100
PLUG M20X1,5 WS=13
252 Kč
32 0770170200
O-RING 17,00X2,00
18 Kč
33 07701250151
O-RING 12,5X1,5 VITON V75
76 Kč
34 59038016100
OIL SCREEN
278 Kč
36 77038005044
OIL FILTER WITH GASKET 06
217 Kč
37 07700390261
O-RING 39,34X2,62
18 Kč
38 75038041200
OIL FILTER COVER
135 Kč
39 0770125015
O-RING 12,5X1,5 NBR
20 Kč
40 0025050166
HH COLLAR SCREW M5X16 TX30
20 Kč
41 0401090003
BALL DIN5401-9
33 Kč
42 58038023300
PRESSURE SPRING L=25MM D=1MM
66 Kč
44 0908120153
THREADED PLUG DIN 908 M12X1.5
87 Kč
45 78040028000
BUSHING PIN
124 Kč
46 0988172405
SHIM WASHER DIN0988-17X24X0,5
15 Kč
47 0471170010
CIRCLIP DIN0471-17X1
17 Kč
48 0912060208
AH SCREW DIN0912-M 6X20 SS
23 Kč
99 78938015010
OILFILTER SERVICEKIT SX-F 15
927 Kč

Další schémata

BALANCER SHAFT BALANCER SHAFT CLUTCH CLUTCH CLUTCH COVER CLUTCH COVER COOLING SYSTEM COOLING SYSTEM CRANKSHAFT, PISTON CRANKSHAFT, PISTON CYLINDER CYLINDER CYLINDER HEAD CYLINDER HEAD ELECTRIC STARTER ELECTRIC STARTER ENGINE CASE ENGINE CASE IGNITION SYSTEM IGNITION SYSTEM LUBRICATING SYSTEM LUBRICATING SYSTEM SHIFTING MECHANISM SHIFTING MECHANISM THROTTLE BODY THROTTLE BODY TIMING DRIVE TIMING DRIVE TRANSMISSION I - MAIN SHAFT TRANSMISSION I - MAIN SHAFT TRANSMISSION II - COUNTERSHAFT TRANSMISSION II - COUNTERSHAFT VALVE DRIVE VALVE DRIVE WATER PUMP WATER PUMP

LUBRICATING SYSTEM

Zvětšit schéma LUBRICATING SYSTEM
LUBRICATING SYSTEM
