Díly pro HANDLEBAR, CONTROLS
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 47102001000 HANDLEBAR 85SX 2013 |
2 819 Kč | |
| 2 | 50302020000 PROTECTION COVER \'97 |
280 Kč | |
| 3 | 80302602044 BAR PAD CPL. |
570 Kč | |
| 4 | 51502010200 THROTTLE GRIP CPL. 2ST. 13 |
1 407 Kč | |
| 5 | 80302021000 GRIP SET BLACK/WHITE |
517 Kč | |
| 8 | 50311089200 SHORT CIRCUIT BUTTON 02 |
626 Kč | |
| 9 | 51502091200 THROTTLE CABLE 2-ST. 2014 |
894 Kč | |
| 20 | 72002030100 MASTER CYLINDER CPL. 10MM |
7 154 Kč | |
| 21 | 72002003000 COVER F. MASTER CYLINDER CPL. |
813 Kč | |
| 22 | 72002032000 REP. KIT PISTON 10MM |
940 Kč | |
| 23 | 72013002000 LEVER CPL. |
1 439 Kč | |
| 24 | 70002038000 LEVER SCREW CPL. |
481 Kč | |
| 25 | 72002037000 MUDCOVER CLUTCH LEVER |
355 Kč | |
| 26 | 72013005000 CLAMP |
546 Kč | |
| 28 | 47132063000 CLUTCH PIPE |
1 296 Kč | |
| 29 | 0770080019 O-RING 8,00X1,00 FORMULA |
45 Kč | |
| 30 | 47013025000 HOLLOW SCREW BRAKE CYLINDER 03 |
207 Kč | |
| 31 | 72002035000 SPRING FOR CLUTCH LEVER |
45 Kč |
