Díly pro REAR WHEEL
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 2611000104430 REAR WHEEL CPL. 5X17\'\' |
20 795 Kč | |
| 2 | 25010010144 REARHUB CPL. |
5 884 Kč | |
| 3 | 77710011000 BEARING DISTANCE TUBE 121,5MM |
323 Kč | |
| 4 | 0625060058 GR.BALL BEAR.6005 DDU2CG23S6NM |
244 Kč | |
| 5 | 0472047175 CIRCLIP DIN0472-47X1,75 |
29 Kč | |
| 6 | 0760324771 SHAFT SEAL RING 32X47X7 BSL |
61 Kč | |
| 7 | 77710016000 DISTANCE BUSHING REAR WHEEL |
494 Kč | |
| 8 | 58309071100 SPOKE M5X174-13,5G 17\'\' |
61 Kč | |
| 9 | 60310072100 SPOKE NIPPLE QUADRAX M5 |
28 Kč | |
| 10 | 5941007000030 REAR RIM 5,0X17\'\' |
Na dotaz | 1 |
| 11 | 77310060000 BRAKE DISC REAR 220 |
2 518 Kč | |
| 12 | 59009062013 SPECIAL SCREW M6X13 WS=8 10.9 |
20 Kč | |
| 13 | 58309073000 RIM TAPE 17\" |
198 Kč | |
| 14 | 77710015000 DISTANCE RING |
28 Kč | |
| 15 | 77710015010 REAR WHEEL REP. KIT |
1 371 Kč | |
| 19 | 58310051042 REAR SPROCKET 42-T |
1 051 Kč | |
| 19 | 58310151040 REAR SPROCKET 40-T |
1 051 Kč | |
| 19 | 58310151048 REAR SPROCKET 48-T |
1 051 Kč | |
| 19 | 58310151050 REAR SPROCKET 50-T |
1 051 Kč | |
| 19 | 58310151052 REAR SPROCKET 52-T |
1 051 Kč | |
| 19 | 7771015104501 SPROCKET 45-T |
1 051 Kč | |
| 19 | 7771015104901 SPROCKET 49-Z |
1 051 Kč | |
| 19 | 7771015105101 SPROCKET 51-Z NATURE |
1 051 Kč | |
| 21 | 0019080266S COUNTER-SUNK SCREW ISA45 M8X26 |
33 Kč | |
| 22 | 06923080003 HEX NUT EN 1661 M8 WS13 |
23 Kč | |
| 23 | 78010167118 CHAIN DID 118 ROLLS |
2 577 Kč | |
| 24 | 78010166000 CONNECTING LINK F. 78010167118 |
199 Kč | |
| 38 | 55003135000 PLUG FOR RIM |
29 Kč | |
| 39 | 50210086000 COVERING CAP SFL16 |
33 Kč | |
| 40 | 77710085044 WHEEL SPINDLE CPL. \'13 |
1 638 Kč | |
| 41 | 77710084000 CHAIN TENSIONER R/S |
326 Kč | |
| 42 | 50304040100 SCREW M10X1.25X50 WS10 |
65 Kč | |
| 43 | 58414030000 HH COLLAR NUT M10X1,25 WS=13 |
36 Kč | |
| 44 | 61010086000 COLLAR NUT M25X1,5 WS=32 05 |
403 Kč | |
| 98 | 00050002038 DRIVETRAIN KIT SMR 14T/48T |
3 186 Kč |
