Díly pro KICK STARTER
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 31 | 47033040000 STOP DISC 15X25X1 |
31 Kč | |
| 48 | 0471190120 CIRCLIP DIN0471-19X1,2 |
5 Kč | |
| 50 | 47033050100 KICKSTARTER SHAFT 85 SX LONG |
1 280 Kč | |
| 51 | 47033051000 KICKSTART GEAR 85 SX 2003 |
1 780 Kč | |
| 52 | 47033052000 RATCHET GEAR 85 SX 2003 |
1 381 Kč | |
| 53 | 47033053000 KICKST. INTERMEDIATE GEAR 2003 |
1 275 Kč | |
| 54 | 47033054000 KICKSTART SPRING 85 SX 2003 |
89 Kč | |
| 55 | 46033055000 DRIVING HUB |
113 Kč | |
| 56 | 47033056000 RATCHET GEAR SPRING 85 SX 2003 |
280 Kč | |
| 59 | 47033059000 SPRING SPACER 85 SX 2003 |
89 Kč | |
| 68 | 0760142460 RADIAL SHAFT SEAL 14X24X6 B |
77 Kč | |
| 70 | 47033070000 KICKSTARTER CPL. 85 SX 2003 |
2 530 Kč | |
| 75 | 0015060163 HH COLLAR SCREW M 6X16 WS=8 |
17 Kč | |
| 76 | 0015050253 HH COLLAR SCREW M 5X25 WS=8 |
20 Kč |
