Díly pro SHIFTING MECHANISM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 47034001000 SHIFT FORK 5TH/6TH GEAR 2003 |
1 150 Kč | |
| 2 | 47034002000 SHIFT FORK 2ND/3RD GEAR 2003 |
1 198 Kč | |
| 3 | 47034003000 SHIFT FORK 1ST/4TH GEAR 2003 |
1 198 Kč | |
| 5 | 47034005044 SHIFTING SHAFT CPL. 85 SX 2003 |
2 862 Kč | |
| 9 | 46034009000 PRESSURE SPRING SLIDER PLATE |
42 Kč | |
| 10 | 47034091000 WASHER 15X20X0,5 |
66 Kč | |
| 11 | 0625069020 BALL BEARING 6902 15X28X7 |
328 Kč | |
| 12 | 47034012000 SHIFT ROLLER 85 SX 2003 |
1 714 Kč | |
| 13 | 47034092000 WASHER 25X32X0,5 |
45 Kč | |
| 14 | 46034014000 RETURN SPRING |
69 Kč | |
| 15 | 47034015000 SHIFT LOCATION DRUM 85 SX 2003 |
1 940 Kč | |
| 16 | 0025060256 HH COLLAR SCREW M6X25 TX30 |
29 Kč | |
| 17 | 0402061200 NEEDLE ROLLER DIN5402 NRB 6X12 |
71 Kč | |
| 18 | 46034019052 SPRING SHIFT RAIL 2001 |
61 Kč | |
| 19 | 47034019000 SHIFTING RAIL 85 SX 2003 |
180 Kč | |
| 20 | 46034020100 SHIFT RAIL 2001 |
185 Kč | |
| 21 | 0625618050 BALL BEARING 61805 C3 |
601 Kč | |
| 23 | 46034023100 LOCKING LEVER SPRING 2001 |
58 Kč | |
| 24 | 46034024100 LOCKING LEVER CPL. 65 SX 2002 |
401 Kč | |
| 25 | 0025080206 HH COLLAR SCREW M8X20 TX40 |
33 Kč | |
| 26 | 47034052000 SLEEVE LOCKING LEVER |
57 Kč | |
| 29 | 47034029000 ARRESTER FOR SPRING 2003 |
82 Kč | |
| 30 | 0933060205 HH SCREW DIN933 M6x20 10.9 |
25 Kč | |
| 31 | 47034031000 SHIFT LEVER 85 SX 2003 |
1 230 Kč | |
| 32 | 0760142460 RADIAL SHAFT SEAL 14X24X6 B |
77 Kč | |
| 33 | 54632095000 NEEDLE SLEEVE HK 1412 14X20X12 |
97 Kč | |
| 34 | 47033043000 STOP DISC 15X25X0,5 |
94 Kč | |
| 41 | 50233041000 PAIR OF WASHERS M 6 NORDLOCK |
39 Kč | |
| 50 | 50232050001 STEEL WASHER 6,4X17X3 |
37 Kč |
