Díly pro WATER PUMP
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 5 | 61230045000 CAP NUT M6 STAINLESS STEEL |
20 Kč | |
| 6 | 81235055020 WATER PUMP ROTOR |
126 Kč | |
| 7 | 81235055110 DISC WATER PUMP |
113 Kč | |
| 8 | 0760123073 SHAFT SEAL RING 12X30X7 PTFE |
212 Kč | |
| 11 | 79435053000 SEAL WITH CARRIER PLATE |
502 Kč | |
| 12 | 79435052000 WATER PUMP COVER |
302 Kč | |
| 13 | 0025060256 HH COLLAR SCREW M6X25 TX30 |
29 Kč | |
| 14 | 0025060456 HH COLLAR SCREW M6X45 TX30 |
29 Kč | |
| 15 | 0025060206 HH COLLAR SCREW M6X20 TX30 |
29 Kč | |
| 16 | 0603061001 CU-SEAL RING DIN7603-6X10X1 |
20 Kč | |
| 17 | 0402040980 NEEDLE ROL.DIN5402 NRB 4X9,8 |
23 Kč | |
| 99 | 79435055015 WATER PUMP REP. KIT |
870 Kč |
