Díly pro REAR WHEEL
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 46310001044 REAR WHEEL CPL. 1,6X12\'\'EXCEL16 |
9 982 Kč | |
| 2 | 46310010044 REAR WHEEL HUB CPL. 65SX 2016 |
5 102 Kč | |
| 7 | 4621007000030 RIM REAR 12\'\'X1,6 BLACK 2009 |
3 595 Kč | |
| 8 | 46210072000 SPOKE NIPPLE ALU |
29 Kč | |
| 9 | 0625060037 GR.BALL BEAR. 6003-2RSH/C3HMTF |
391 Kč | |
| 10 | 0625062032 GR.BALL BEAR. 6203-2RSHC3HMTF |
225 Kč | |
| 11 | 46010011000 BEAR.SPACER TUBE REAR SX 60/65 |
453 Kč | |
| 12 | 59009062016 SPECIAL SCREW M6X16 WS=8 10.9 |
31 Kč | |
| 13 | 46310013000 SPACER BUSHING L/S |
345 Kč | |
| 14 | 46310014000 SPACER BUSHING R/S |
295 Kč | |
| 15 | 46210071140 SPOKE 3X140 C. 150° C.5 Zinc |
36 Kč | |
| 16 | 46210071133 SPOKE 3X133 C.161 C.4 Zinc |
36 Kč | |
| 17 | 0991080253 FLAT HEAD SCREW DIN7991-M 8X25 |
31 Kč | |
| 18 | 54310086200 SELF LOCKING NUT M8 10.9 |
21 Kč | |
| 19 | 46010051046 REAR SPROCKET 46-T |
1 152 Kč | |
| 19 | 46010051048 REAR SPROCKET 48-T |
1 152 Kč | |
| 19 | 46010051050 REAR SPROCKET 50-T |
1 152 Kč | |
| 22 | 46310085044 AXLE REAR CPL. 2016 |
1 535 Kč | |
| 23 | 45109073100 RIM BAND 12\'\' |
219 Kč | |
| 30 | 46210060000 BRAKE DISC REAR 65 SX 09 |
1 605 Kč | |
| 47 | 46310084000 CHAIN TENSIONER R/S |
358 Kč | |
| 48 | 77204087000 HEX NUT M14X1.5 WS17 |
55 Kč | |
| 50 | 46110165112 CHAIN 1/2X1/4\'\' 65 SX |
764 Kč | |
| 51 | 46110166000 CONNECTING LINK 1/2X1/4\'\' |
77 Kč | |
| 55 | 78109090000 RIM LOCK 1,60\'\' |
375 Kč | |
| 56 | 77110090050 NUT FOR WHEEL HOLDER |
33 Kč | |
| 98 | 46310015000 REAR WHEEL REP. KIT 65 SX 2016 |
1 503 Kč | |
| 99 | 00050000919 SPOKE KIT REAR 12\'\' \'12 |
1 381 Kč |
