Díly pro SWING ARM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 46304030044 SWING ARM CPL. 65 SX 2016 |
13 668 Kč | |
| 3 | 54603097000 NEEDLE BUSH HK 2016 |
221 Kč | |
| 4 | 46004030070 SPACER BUSHING 20X26X30X9,7 |
33 Kč | |
| 5 | 77204041000 CLOSING COVER |
66 Kč | |
| 6 | 46004030071 BUSHING BOX 12X20X36,5 |
316 Kč | |
| 7 | 0770160021 O-RING 16,00X2,00 VITON |
25 Kč | |
| 10 | 46304066000 CHAIN SLID. GUARD |
286 Kč | |
| 11 | 0025060166 HH COLLAR SCREW M6X16 TX30 |
28 Kč | |
| 12 | 83008000012 SPECIAL SCREW M6X12X3 |
44 Kč | |
| 13 | 0009050106 EJOT SPIRAL SCREW SF M5X10-K |
20 Kč | |
| 14 | 46304070000 CHAIN GUIDE |
651 Kč | |
| 15 | 0025060406 HH COLLAR SCREW M6X40 TX30 |
29 Kč | |
| 20 | 77204089000 HH COLLAR SCREW M10X52 SW13 |
57 Kč | |
| 21 | 69004095000 ADAPTOR NUT M10 |
98 Kč | |
| 25 | 46204037033 SWINGARM BOLT CPL. 201MM |
647 Kč | |
| 26 | 0125120003 FLAT WASHER DIN0125-A13 |
17 Kč | |
| 29 | 0934120103 HEXAGON NUT DIN0934-M12X1 |
23 Kč | |
| 31 | 50203030090 HH SCREW M8X40 WS=10 |
55 Kč | |
| 32 | 46030045000 FLANGED NUT M8 WS10 |
87 Kč | |
| 35 | 47113047000 BRAKE HOSE GUIDE |
86 Kč | |
| 97 | 45204230010 SWINGARM REP. KIT 50/65 SX |
1 100 Kč | |
| 98 | 46304066010 CHAIN GUARD KIT 2016 |
324 Kč | |
| 99 | 46307066010 CHAIN GUIDE KIT REAR 2016 |
685 Kč |
