Díly pro FRONT FORK, TRIPLE CLAMP
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 14182N40E FORK 450 RALLY |
64 175 Kč | |
| 2 | 0025080256 HH COLLAR SCREW M8X25 TX40 |
33 Kč | |
| 3 | 0025080306 HH COLLAR SCREW M8X30 TX40 |
32 Kč | |
| 4 | 0025080256S HH COLLAR SCREW M8X25 TX40 |
33 Kč | |
| 5 | 0025080206 HH COLLAR SCREW M8X20 TX40 |
33 Kč | |
| 6 | 36003014000 LOCK WASHER 8MM |
15 Kč | |
| 7 | 77701084000 O-RING SUPPORT W. SEALING LIP |
332 Kč | |
| 8 | 54201081100 TAPERED ROLLER BEARING CPL. 06 |
756 Kč | |
| 9 | 54601184000 STEARING HEAD GASKET TOP |
114 Kč | |
| 10 | 7620108600030 STEER HEAD COV SHORTENED BLK |
400 Kč | |
| 11 | 0770025035 O-RING 25X3,55 NBR70 05 |
17 Kč | |
| 12 | R0502003000 GPS SUPPORT MILLED 07 |
4 551 Kč | |
| 13 | 50211096000 CLAMP FOR WIRING HARNESS |
42 Kč | |
| 14 | 0025050166 HH COLLAR SCREW M5X16 TX30 |
20 Kč | |
| 15 | SXS07125200 PROGRESSIVE HANDLEB.SUPP.PHDS |
4 706 Kč | |
| 16 | 0032100356S AH-COLLAR SCREW M10X35 ISA45 |
36 Kč | |
| 16 | 0912100256 AH SCREW DIN0912-M10X25 10.9 |
44 Kč | |
| 17 | SXS05125203 ELASTOMER GREEN/SOFT |
262 Kč | |
| 17 | SXS05125204 ELASTOMER YELLOW/MEDIUM |
262 Kč | |
| 17 | SXS05125205 ELASTOMER RED/HARD |
262 Kč | |
| 18 | 0025080456 HH COLLAR SCREW M8X45 TX40 |
33 Kč | |
| 19 | 58512050100 STEERING DAMPER |
15 744 Kč | |
| 20 | 76403001079 STEERING DAMPER BRACKET CPL. |
3 141 Kč | |
| 21 | 0912060253 AH SCREW DIN0912-M 6X25 |
29 Kč | |
| 22 | 54801036000 STEER.HEAD SCREW M20X1,5 WS=27 |
185 Kč | |
| 24 | 58502006100 PIN F.STEERING STAB. 8MM 05 |
765 Kč | |
| 25 | 46030045000 FLANGED NUT M8 WS10 |
87 Kč | |
| 26 | 0012060164 AH SCREW DIN6912 M6X16 SL |
36 Kč | |
| 27 | 76401034222HA TOP TRIPLE CLAMP X=22MM |
7 662 Kč | |
| 28 | 76401032222HA BOT. TRIPLE CLAMP CPL. |
7 662 Kč | |
| 29 | 0025080506 HH COLLAR SCREW M8X50 TX40 |
33 Kč |
