Díly pro EXHAUST SYSTEM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 47205079000 SILENCER 85 SX |
4 046 Kč | |
| 2 | 78105081010 SCREW TORX M5X10 |
15 Kč | |
| 3 | 0011480800 DUMMY RIVET 4,8X 8 NIRO |
39 Kč | |
| 4 | 0770740015 O-RING 74,00X1,50 FKM 75SH |
58 Kč | |
| 5 | 47205079060 ENDCAP CPL. |
1 280 Kč | |
| 6 | 47205078165 STUFFINGYARN PACKAGE 165G |
1 346 Kč | |
| 7 | 77205068000 DAMP. COMPON. BLACK |
69 Kč | |
| 8 | 47205058000 HOSE SPRING |
190 Kč | |
| 9 | 47205057000 EXHAUST RUBBER |
318 Kč | |
| 10 | 47205007000 MANIFOLD |
5 448 Kč | |
| 11 | 50305016000 TEN.SPRING L=62MM EY.MOVEABLE |
98 Kč | |
| 12 | 0770380030 O-RING 38,00X3,00 VITON |
58 Kč | |
| 13 | 50305012000 SWINGELEMENT FOR EXHAUST PIPE |
257 Kč | |
| 14 | 0024060156 HH COLLAR SCREW M6X15 TX30 |
29 Kč | |
| 15 | 0025060356 HH COLLAR SCREW M6X35 TX30 |
29 Kč | |
| 17 | 50233041000 PAIR OF WASHERS M 6 NORDLOCK |
39 Kč | |
| 18 | 77205169000 BUSHING 7.5x12x28x8.3 11 |
82 Kč | |
| 19 | 54603048100 CLIP NUT M6 |
87 Kč | |
| 99 | 00050000812 EXHAUST HARDWARE KIT MINI |
1 280 Kč |
