Díly pro FRONT FORK DISASSEMBLED
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 48601318S1 AXLE CLAMP L/S WITH TUBE CPL. |
11 457 Kč | |
| 2 | 48601317S1 AXLE CLAMP R/S WITH TUBE CPL. |
11 457 Kč | |
| 3 | R14040 GASKET KIT CPL. |
1 764 Kč | |
| 4 | 48601062S2 SCREW CAP M51X1.5 REB |
684 Kč | |
| 5 | 48601062S3 SCREW CAP M51X1.5 COM |
684 Kč | |
| 6 | 46810340 O-RING NBR 45X2 |
41 Kč | |
| 7 | R14026 SPRING SPACER KIT |
408 Kč | |
| 8 | 48601099 OUTER TUBE L=550 D54/D60 3L |
4 924 Kč | |
| 9 | R14063 FORK REP. KIT 48MM OFFROAD |
1 960 Kč | |
| 10 | 48600705S3 CARDRIDGE KIT CPL. R/S |
4 786 Kč | |
| 11 | 48601319S CARDRIDGE KIT CPL. L/S |
4 786 Kč | |
| 12 | 91410044S SPRING C=5,6 L=450 D=5,5 05 |
3 382 Kč | |
| 13 | 00501020S1 AH SCREW M10X20 SET |
94 Kč | |
| 97 | 48601166S1 FORK OIL SAE4 5L |
2 949 Kč | |
| 98 | T14034 FUCHS GREASE IPR (250G) |
1 280 Kč | |
| 99 | R14041 REP. KIT 1290 SD 2014 |
2 207 Kč |
