Díly pro INSTRUMENTS / LOCK SYSTEM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 27014169100 DIGITALTACHO 17\'\' |
6 992 Kč | |
| 2 | 58214069051 RUBBER GROMMET 16X10.8X3 |
61 Kč | |
| 3 | 0081045121 SCREW FOR PLASTIC K45X12 T20 |
21 Kč | |
| 4 | 27014060000 SPEEDOMETER BRACKET |
979 Kč | |
| 5 | 27014081000 FLASHER CONTROL LIGHT |
619 Kč | |
| 6 | 58011025000 OIL INDICATOR LIGHT RED |
68 Kč | |
| 7 | 58011023300 NEUTRAL INDIC. LIGHT GREEN \'98 |
68 Kč | |
| 8 | 60142070100 SWITCH ABS |
1 475 Kč | |
| 9 | 75014010050 COLLAR BUSHING 6,1X8,1X14X8 07 |
55 Kč | |
| 10 | 31008060000 RUBBER GROMMET D=8MM OPEN |
61 Kč | |
| 11 | 0024060156 HH COLLAR SCREW M6X15 TX30 |
29 Kč | |
| 12 | 69008021160 SPECIAL SCREW M5X12 |
52 Kč | |
| 13 | 27011067000 IGNITION KEY CPL. |
2 776 Kč | |
| 14 | 27011066044 LOCK SET |
7 661 Kč | |
| 15 | 27011066000 IGNITION LOCK |
6 111 Kč | |
| 16 | 59009062013 SPECIAL SCREW M6X13 WS=8 10.9 |
20 Kč | |
| 17 | 0770100020 O-RING 10.00X2.00 SILICONE |
18 Kč | |
| 18 | 27007008000 TANK CAP |
4 486 Kč |
