Díly pro REAR BRAKE CALIPER
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 45213080000 BRAKE CALIPER REAR |
4 621 Kč | |
| 2 | 45113019100 REPAIR KIT BRAKEPISTON |
206 Kč | |
| 3 | 0770022020 O-RING 22X2X2 EPDM |
150 Kč | |
| 4 | 0770060019 O-RING 6,00X1,00 FORMULA |
45 Kč | |
| 5 | 45113018000 RETAINING SPRING 50 LC |
331 Kč | |
| 6 | 45113030000 BRAKE PAD SET 50 LC 2002 |
977 Kč | |
| 7 | 45113225000 AH SCREW + CIRCLIP 50/65 04 |
263 Kč | |
| 8 | 0799025000 TAB WASHER DIN6799 RS2,5 |
61 Kč | |
| 9 | 46113225000 HOLLOW SCREW CPL. |
458 Kč | |
| 10 | 0912050163 AH SCREW DIN0912-M 5X16 |
17 Kč | |
| 11 | 0025060166 HH COLLAR SCREW M6X16 TX30 |
28 Kč | |
| 12 | 0025060406 HH COLLAR SCREW M6X40 TX30 |
29 Kč | |
| 13 | 0770080019 O-RING 8,00X1,00 FORMULA |
45 Kč | |
| 14 | 45119050000 BLEEDER INJECTION-SET 50-65 |
693 Kč |
