Díly pro COOLING SYSTEM
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 47235008000 RADIATOR RIGHT |
4 807 Kč | |
| 2 | 79035016000 RADIATOR CAP 1,8 BAR |
390 Kč | |
| 3 | 47235007000 RADIATOR LEFT |
4 807 Kč | |
| 4 | 47235025000 RADIATOR CONNECTOR TOP |
158 Kč | |
| 5 | 47235026000 PREFORMED HOSE ENGINE |
190 Kč | |
| 6 | 47235027000 PREFORMED HOSE WATER PUMP |
190 Kč | |
| 7 | 10001020300 HOSE CLAMP 18-29 |
52 Kč | |
| 8 | 59007017000 CLAMP YDNAC 10096F (9,6MM) |
20 Kč | |
| 9 | 50335030001 PVC-HOSE 6X9 |
92 Kč | |
| 10 | 51030022000 ANGLE PIECE 90 DEGREE M10X1 |
43 Kč | |
| 11 | 47235034000 RADIATOR PROTECTION |
286 Kč | |
| 12 | 0024060156 HH COLLAR SCREW M6X15 TX30 |
29 Kč | |
| 13 | 0024060123 COLLAR SCREW M6X12 TX |
23 Kč | |
| 14 | 47235033000 RADIATOR COVER FULL |
190 Kč | |
| 15 | 47235033100 RADIATOR COVER HALF |
190 Kč |
