Díly pro ENGINE CASE
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 47230000044 ENGINE CASE CPL. |
12 851 Kč | |
| 2 | 54630027000 DOWEL BUSHING 13,8X11X12 |
143 Kč | |
| 3 | 54830027000 DOWEL 21X12 03 |
103 Kč | |
| 4 | 54634049000 RETAINING PLATE |
50 Kč | |
| 5 | 0025060126 HH COLLAR SCREW M6X12 TX30 |
29 Kč | |
| 6 | 47230039000 CRANKCASE COVER GASKET |
406 Kč | |
| 7 | 55430090000 BRACKET FOR BLEEDING TUBE |
158 Kč | |
| 8 | 47230025000 GASKET INNER CLUTCH COVER |
414 Kč | |
| 9 | 47230001000 INNER CLUTCH COVER |
3 707 Kč | |
| 10 | 0770191015 O-RING 19,00X3,00 NBR |
15 Kč | |
| 11 | 79430020000 |
Na dotaz | 1 |
| 12 | 47230027000 CLUTCHCOVER GASKET |
254 Kč | |
| 13 | 47230626000KA CLUTCH COVER CPL. |
1 431 Kč | |
| 14 | 47235053000 GASKET WITH SUPPORTHEET |
639 Kč | |
| 15 | 47235052000 WATERPUMP COVER |
639 Kč | |
| 16 | 0402040980 NEEDLE ROL.DIN5402 NRB 4X9,8 |
23 Kč | |
| 17 | 0603061001 CU-SEAL RING DIN7603-6X10X1 |
20 Kč | |
| 18 | 49030090100 DOWEL 9,8 X7X10 |
52 Kč | |
| 19 | 58038022000 CU-SEAL RING DIN7603-12X18X1,5 |
28 Kč | |
| 20 | 58030021100 OILDRAIN PLUG WITH MAGNET |
196 Kč | |
| 21 | 0760193070 SHAFT SEAL RING 19X30X7 B |
77 Kč | |
| 22 | 54637070100 COVER LID 250-380\'98 |
265 Kč | |
| 23 | 50433024050 BUSHING IDLER GEAR |
424 Kč | |
| 30 | 0014050203 HH COLLAR SCREW M 5X20 WS=6 |
55 Kč | |
| 31 | 0025060106 HH COLLAR SCREW M6X10 TX30 |
28 Kč | |
| 32 | 0025060256 HH COLLAR SCREW M6X25 TX30 |
29 Kč | |
| 33 | 0025060456 HH COLLAR SCREW M6X45 TX30 |
29 Kč | |
| 34 | 0025060506 HH COLLAR SCREW M6X50 TX30 |
29 Kč | |
| 35 | 0025060606 HH COLLAR SCREW M6X60 TX30 |
29 Kč | |
| 36 | 0025060556 HH COLLAR SCREW M6X55 TX30 |
29 Kč | |
| 99 | 47230099000 GASKET SET 85 SX 2018 |
4 486 Kč |
